1252XX-XXTW-L

	1252S-xxTW-L 1252R-xxTW-L 1252MR-xxGW-U 1252MS-1xxGW-U 1252MS-2xxGW-U
Number of contact	1- row 2 bis 15, 2row 10,14,20,30,40
Performance
Insulator	Nylon 6T, nach UL94 V-0
Contact Material	Phosphor Bronze
Plating	Tin plating / Gold plating
Solderability	IEC 60512-12A
Proccessing	Reflow SMT soldering
Packaging	Bulk
Partnumber example	1252S-10TW-L
	Catalog page / Datasheet
	3D PDF File on request
