Plastic fiber cable duplex 1/6.4mm high flex PUR jacket red
This indoor cable enables the direct connector assembly. The robust fiber optic cable is applicable for use in industrial environments. The fibers are characterized by their excellent mechanical and optical properties.
 |
|
Outer diameter
|
cable
6.4mm
buffer tube
2.2mm
|
| Cladding diameter |
1000 µm |
| Core diameter |
980 µm |
Buffer tube
|
inner jacket
PE - polyethylene, black/blue
outer jacket
PUR - polyurethane, red
|
Type designations
|
I-V2Y(ZN)11Y 2P980/1000 FLEX |
Number of fibers
|
2
|
Operating temperature
|
-40 to +80°C
|
| Data sheet |
on request |
| Ordering information |
93FIPUN10000602RT-CD |
| Additional information |
- flame-retardant, LSOH according IEC 60754-2
- resistance against oil, petrol, acid and leach
- outer jacket is UV resistant according to DIN EN ISO 4892-2
|
